In car wash and other caustic applications, garage door technology is tested to the limit. That’s why Encore Garage Door Systems feature Nystroll Roller state-of-the-art technology for extremely demanding applications. In a high-cycle environment where repetitive movements can result in serious wear and tear on components, the bearing-less Nystroll Roller has proven itself to perform consistently and quietly with little or no maintenance required.

Key Features & Benefits:

• Stainless-steel shaft and clip are corrosion resistant for extended life and strength
• Available in 50.8 mm (2”) or 76.2 mm (3”) rollers and 127 mm (5”), 177.8 mm (7”) and 228.6 mm (9”) stem lengths
• Nylon roller is quiet and durable
• Thoroughly tested and negligible — only wears at 200,000+ cycles
• Self-lubricating, grease-packed bronze bushing
• No ball bearings to rust

The EZ123 Universal Bottom Bracket’s unique design allows for easy implementation and replacement of bottom rollers in tight installations, eliminating the need to take tension off the springs, clamp cables, or the bending or forcing of roller out of track. The bottom bracket is designed for both 50.8 mm (2”) and 76.2 mm (3”) rollers, which minimizes inventory costs. It can be used on all sectional door types, 38.1 mm (1-1/2”) up to 76.2 mm (3”) thick, including Aluminum Full View Doors. Made from heavy duty 12-gauge galvanized steel with aluminum roller holder, with a built-in pull cord/chain attachment, the EZ123 is designed to be the safest multi-purpose bottom bracket in the industry.

Key Features & Benefits:

• Replaces bottom roller quickly & easily in tight installations
• No bending or forcing roller out of track
• Safely eliminates the need to take tension off spring or clamp cables
• Universal design for 50.8 mm (2”) and 76.2 mm (3”) track
• Adapts to all sectional doors including Aluminum Full view doors
• Heavy duty 12-gauge galvanized with aluminum roller holder
